High juice yield orange juice production and packaging line big
capacity
Description
Shanghai Gofun machinery company, a professional citrus processing
line manufacturer and exporter in China. Which can provide turnkey
solution and technical support for citrus processing line with
different kinds of end products from citrus and all kinds of
package.
Citrus processing line can produce from fresh citrus to different
kinds of final product. The raw material can be all kinds of citrus
fruits, including orange, mandarin, lemon, grapefruit, etc. And the
final product can be clear juice, cloudy juice, juice brink, juice
concentrate, oil, etc. For the package, it can be aseptic bags,
sachet, stand-up pouch, metal can, PP container, PET bottle, glass
bottle, gable top, etc. All kinds of citrus product are very
popular all over the world.
Technical Paraments
| Raw material | Fresh orange, lemon, mandarin, tangerine, grapefruit, etc. |
| End product | Concentrated Juice, NFC juice, Oil, etc. |
| Processing capacity | From 20 ton/day to 1500 ton/day |
| Efficient input | 45% raw fruit (55% as waste, peels and seeds) |
| Fruit consistence | 7~12Brix |
| End package | Aseptic bag, metal can, glass bottle, PET bottle |
Raw Material
Advantages
The citrus processing line from Shanghai Gofun machinery company is
running with high effective, water saving, high extracting rate,
safety quality control for final product, safety control for
operators, etc.
Flowchart
Citrus Juice Processing Line
CLOUDY JUICE: FRESH CITRUS ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒
EXTRACTING ⇒ PULPER & REFINER ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒
STORAGE OR BLENDING
CLEAR JUICE: FRESH CITRUS ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ EXTRACTING ⇒ PULPER &
REFINER ⇒ ENZYMATIC HYDROLYSIS & FILTRATION SYSTEM ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING
Main configuration
| Main configuration of the system |
| No. | Item | Brand |
| 1 | PLC | Siemens |
| 2 | Human Machine Interface | Siemens |
| 3 | Steam Reducing Valve | Spirax Sarco |
| 4 | Steam Regulating Valve | Spirax Sarco |
| 5 | Steam Trap Valve | Spirax Sarco |
| 6 | Electric Elements | Schneider |
| 7 | Transducer | Japan Fujifilm |
| 8 | Temperature paperless recorder | YOKOGAWA |
| 9 | Breaker | Schneider |
| 10 | Central relay | Omron |
After-Sales Service
1. Oversea technical support
2. Oversea equipment maintenance
3. English speaking engineers available to provide technique
support
Company Information
Gofun Company provides the turn-key solution for not only the
tomato paste production line but also the processing and packaging
lines for apple, pear, peach, mango, and apricot and other fruits &
vegetables, and has received wide spread praises from customers in
both the domestic and overseas markets. The machines have already
been exported to all over the world including the Asian countries,
African countries, South American countries and even European and
American countries. Gofun Company aim to create the outstanding
food machinery and contribute to the world's agricultural industry.
We sincerely committed ourselves to a brilliant prospect and mutual
benefit relationship with all of the people and friends from
Worldwide!
