Automatic Mango Pulp Production Plant Aseptic Bag In Drum Package Industrial Use

Shanghai Gofun machinery company offers all kinds of mango processing line.The raw material can be fresh mango, mango concentrate juice, etc. And the final product can be mango paste, mango juice, mango beverage, mango powder, etc. For final package, it can be aseptic bag, metal can, sachet, stand-up pouch, PP container, glass bottle, PET bottle, gable top, etc.

The mango processing line from Shanghai Gofun machinery company is running with high effective, water saving, high extracting rate, safety quality control for final product, safety control for operators, etc.

Project introduction

Mango processing line can produce from fresh mango to different kinds of final product. For example, mango juice, mango paste, mango pulp, dried mango. And the mango product is getting more and more popular in Chinese market. To reach the increasing requirement of mango product, Shanghai Gofun machinery company has created a mango processing segment that provides all of the necessary mango processing machinery for all kinds of mango product. For example, mango concentrate juice, mango juice, mango puree, dried mango, etc.

Mango Juice Processing Line

CLEAR JUICE: FRESH MANGO ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ DESTONING ⇒ PREHEATING ⇒ PULPER & REFINER ⇒ ENZYMATIC HYDROLYSIS & FILTRATION SYSTEM ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING

CLOUDY JUICE: FRESH MANGO ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ DESTONING ⇒ PREHEATING ⇒ PULPER & REFINER ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING

Washing

Before crushing, need to washing fresh mango carefully. For washing we can use bubble washing machine and spray washing machine together. If the washing requirement is high, can add more stages of washing. Also for better cleaning effect, we can add ultrasonic cleaning and ozone cleaning. After bubble washing machine, will use brush and spray washing machine to make the fresh mango cleaner.

Sorting

After washing, the surface of mango is clean, we can check the situation of all the mango by eye. And sort out the bad mango by human.

Destoner

The mango destoner is running with speed of 1470 r/min to crush fresh mango to make sure all the mango cores are fully cleaned. The cores will be sent outside factory, and the pulp will be pumped to next step.

Preheating

The pre-heater is used to heat the product after destoner, the temperature is adjustable, normally from 45℃ to 85℃. This processing step, would help to higher the juice rate for next step, and also can protect the color and testing for final mango paste.

Pulper and refiner

This machine is also running with speed of 1470 r/min, it causes the centrifugal force and the product will go through screen, helps to refine the product. And normally we use double stage of pulper and refiner, the screen of each stage is different, for first stage the screen would be bigger, and for second stage the screen would be smaller.

Company Information

Shanghai Gofun machinery company, a professional vegetable and fruit processing line manufacturer and exporter in China. Which can offer the turn-key solution for different fruits juice, pulp & paste processing complete line with high quality and competitive production lines with daily capacity from 60 tons to 1500 tons and customizations including plant construction, equipment manufacturing, installation, commissioning and production; provide the most optimized implementation plan.Gofun Company provides the turn-key solution for not only the tomato paste production line but also the processing lines for many kinds of fruits & vegetables, like apples, pears, plums, coconuts, mulberries, ect., and has received widespread praises from customers from both the domestic and overseas. Our machines have already been exported to all over the world including the Asian countries, African countries, South American countries and even European countries.

Our Services

1. Technical support

2. Marketing suggestion

3. Final packing suggestion and design

4. Factory building and design

After-Sales Service

1. Oversea technical support

2. Oversea equipment maintenance

3. English speaking engineers available to provide technique support

Shanghai Gofun machinery company, a professional fruit and vegetable processing line manufacturer and exporter in China. Which can offer the turn-key solution for different fruit juice, pulp & paste processing complete line with high quality and competitive production lines with daily capacity from 60 tons to 1500 tons. We can provide the one-stop solution from A to Z, including plant construction, equipment manufacturing, installation, commissioning, and production; provide the most optimized implementation plan.

Gofun Company provides the turn-key solution for not only the tomato paste production line, but also the processing lines for many kinds of fruits & vegetables, like apples, pears, plums, coconuts, mulberries, etc., and has received widespread praises from customers from both the domestic and overseas. Our machines have already been exported all over the world including Asian countries, African countries, South American countries, and even European countries.
